Fiberusbc

Armored 8K HDMI 2.1 Micro HDMI (Type D) to Micro HDMI (Type D) 10m (33ft) Active Optical Cable, 48Gbps, Industrial Grade

Armored 8K HDMI 2.1 Micro HDMI (Type D) to Micro HDMI (Type D) 10m (33ft) Active Optical Cable, 48Gbps, Industrial Grade

常规价格 $80.00 USD
常规价格 促销价 $80.00 USD
促销 售罄
已含税费。
数量

Armored HDMI 2.1 Type D to D Active Optical Cable – 48Gbps, 8K@60Hz

The Armored HDMI 2.1 Type D-to-D Active Optical Cable is designed for high-bandwidth video transmission in demanding and mechanically challenging environments. Featuring a stainless-steel armored structure and hybrid fiber architecture, it provides enhanced protection against crushing and physical stress while supporting up to 48Gbps bandwidth.

The cable is designed to support 8K@60Hz and 4K@120Hz on compatible HDMI 2.1 systems, making it suitable for professional cameras, embedded displays, industrial imaging equipment, and other compact devices equipped with Micro HDMI Type D interfaces.

Its active optical transmission design enables long-distance HDMI connectivity while reducing susceptibility to electromagnetic interference. The combination of optical fiber and copper conductors provides a practical balance between high-bandwidth performance, mechanical protection, and installation flexibility.

With Micro HDMI Type D connectors on both ends, the cable is optimized for compact devices where standard HDMI connectors are too large. The stainless-steel armored construction makes it particularly suitable for installations where the cable may be exposed to compression, abrasion, equipment movement, or demanding routing conditions.

Key Features

  • 48Gbps HDMI 2.1 Bandwidth – Supports high-bandwidth HDMI 2.1 transmission for demanding professional video applications.

  • 8K@60Hz & 4K@120Hz Support – Designed for high-resolution video transmission on compatible HDMI 2.1 systems.

  • Micro HDMI Type D to Type D – Provides direct connectivity between two compact devices equipped with Micro HDMI interfaces.

  • Stainless-Steel Armored Structure – Provides enhanced mechanical protection for demanding installation environments.

  • High Crush Resistance – Designed to withstand greater mechanical pressure than conventional lightweight HDMI cable constructions.

  • Hybrid Fiber + Copper Design – Combines optical fiber transmission with copper conductors for active HDMI connectivity.

  • Active Optical Transmission – Supports long-distance HDMI signal transmission with strong resistance to electromagnetic interference.

  • Compact Device Compatibility – Designed for professional cameras, embedded displays, industrial imaging equipment, and other Micro HDMI devices.

  • Plug and Play – No additional driver or software installation required.

  • CE / FCC Compliant – Designed for professional and industrial application environments.

Professional Applications

Industrial Cameras

The armored structure provides additional mechanical protection for HDMI connections used with industrial cameras, inspection equipment, and machine vision systems.

Professional Camera Systems

Suitable for cameras and imaging equipment equipped with Micro HDMI Type D interfaces, including monitoring and video production applications.

Embedded Displays

The compact Type D connectors are suitable for embedded displays and specialized systems where installation space is limited.

Industrial Imaging

Designed for demanding imaging environments where high-resolution video transmission and enhanced cable protection are required.

Equipment & Machinery

The stainless-steel armored construction helps protect the cable against mechanical stress in equipment, machinery, and fixed industrial installations.

Harsh Installation Environments

Suitable for applications where cables may be exposed to compression, abrasion, equipment movement, or other physical installation challenges.

Technical Specifications

Specification Details
Product Type HDMI 2.1 Active Optical Cable
Connector Configuration Micro HDMI Type D to Micro HDMI Type D
HDMI Version HDMI 2.1
Bandwidth Up to 48Gbps
Resolution Up to 8K@60Hz*
4K Support Up to 4K@120Hz*
Transmission Technology Active Optical
Cable Construction Hybrid Fiber + Copper
Armor Stainless Steel
Mechanical Protection High Crush Resistance
EMI Performance Strong EMI Immunity
Installation Plug and Play
Primary Devices Cameras, Embedded Displays, Industrial Imaging Equipment
Compliance CE / FCC
Applications Industrial, Professional AV, Imaging, Embedded Systems

*Actual resolution, refresh rate, chroma format, and transmission performance depend on the source device, display, Micro HDMI implementation, cable length, and overall system configuration.

Built for Mechanical Protection

Standard fiber optic HDMI cables prioritize flexibility and low weight, but some professional installations require additional physical protection.

This cable uses a stainless-steel armored structure to provide enhanced resistance to crushing and mechanical stress. This makes it a practical choice for installations where cables may pass through equipment, machinery, cable pathways, or other environments where physical protection is important.

The armored construction is combined with an active optical hybrid fiber architecture, allowing the cable to deliver high-bandwidth HDMI 2.1 connectivity while providing additional mechanical protection.

Micro HDMI Connectivity for Compact Systems

The Type D-to-Type D configuration is designed specifically for devices equipped with Micro HDMI interfaces.

It is suitable for compact cameras, embedded displays, industrial imaging equipment, and specialized video devices where a full-size HDMI connector would not be practical.

The combination of Micro HDMI Type D connectors, 48Gbps bandwidth, active optical transmission, and stainless-steel armor makes this cable suitable for specialized professional and industrial video systems.

B2B & Project Applications

Ideal for:

  • Industrial camera manufacturers

  • Machine vision system integrators

  • Professional camera manufacturers

  • Embedded display manufacturers

  • Industrial imaging equipment

  • Inspection and monitoring systems

  • Robotics and automation equipment

  • Professional AV integrators

  • Harsh-environment video installations

  • OEM / ODM equipment manufacturers

  • Custom cable projects

  • Bulk and distribution applications

For OEM, ODM, or project requirements, provide the required cable length, connector configuration, armor requirements, quantity, application environment, and HDMI specification for project evaluation.

Frequently Asked Questions

What connectors does this armored HDMI cable use?

It uses Micro HDMI Type D connectors on both ends, making it suitable for devices equipped with Micro HDMI ports.

Does it support 48Gbps?

Yes. The cable is designed to support up to 48Gbps bandwidth for compatible HDMI 2.1 systems.

Does it support 8K@60Hz and 4K@120Hz?

Yes. It is designed to support up to 8K@60Hz and 4K@120Hz on compatible source and display systems.

What is the purpose of the stainless-steel armor?

The stainless-steel armored structure provides enhanced mechanical protection and high crush resistance, making the cable suitable for demanding installation environments.

Is this cable suitable for industrial cameras?

Yes. The Type D-to-D configuration and armored construction make it suitable for industrial cameras, machine vision systems, inspection equipment, and professional imaging applications using Micro HDMI.

Is this an active optical cable?

Yes. It uses an active optical hybrid fiber architecture for high-bandwidth HDMI signal transmission.

Is it suitable for harsh environments?

It is designed for professional and industrial applications where increased mechanical protection is required. Actual suitability should be evaluated against the specific environmental conditions, including temperature, vibration, chemical exposure, and installation method.

Does it require external power?

The cable is designed for plug-and-play operation without an external power supply. Actual operation depends on the connected HDMI devices and system configuration.

Can custom lengths be produced?

Custom lengths and configurations can be considered for OEM, ODM, and project orders. Provide the required length, Type D connector configuration, armor specification, quantity, and application environment for evaluation.
