The USB-C to HDMI 2.1 Active Optical Cable is a high-performance long-distance display connectivity solution designed for professional AV, broadcast, conference rooms, commercial displays, industrial environments, and high-end visual applications.
Using advanced Active Optical Cable (AOC) technology and a hybrid fiber-optic construction, the cable supports up to 48Gbps bandwidth, enabling high-resolution video transmission up to 8K@60Hz and 4K@120Hz over distances of up to 30 meters.
The optical transmission architecture helps minimize signal degradation and provides strong resistance to EMI/RFI interference, making the cable suitable for environments where stable high-bandwidth video transmission is critical.
The cable features a driver-free, bus-powered, plug-and-play design with hot-plug and auto-detection functionality. No external adapter or signal converter is required for compatible USB-C source devices, providing a clean and reliable installation for professional display systems.
Key Features
-
48Gbps High-Bandwidth Transmission
Supports up to 48Gbps bandwidth for high-resolution HDMI 2.1 display applications.
-
8K@60Hz & 4K@120Hz Support
Designed for ultra-high-resolution and high-refresh-rate visual applications, including professional displays, gaming systems, and advanced AV environments.
-
30m Long-Distance Transmission
Active optical technology enables reliable high-bandwidth video transmission over distances up to 30 meters.
-
Hybrid Fiber-Optic Construction
Uses high-purity optical fiber for high-speed signal transmission combined with copper conductors for power delivery.
-
Low-Loss Optical Transmission
The optical architecture helps reduce signal degradation over extended cable runs compared with conventional copper-only solutions.
-
Strong EMI/RFI Immunity
Optical signal transmission provides strong resistance to electromagnetic and radio-frequency interference, making it suitable for professional and industrial environments.
-
HDR & DSC Support
Supports HDR and Display Stream Compression (DSC) for compatible high-resolution display systems.
-
Dynamic HDR & HDCP 2.3
Designed to support Dynamic HDR and HDCP 2.3 for compatible content and display devices.
-
Driver-Free & Plug-and-Play
Bus-powered operation, hot-plug functionality, and automatic device detection provide a simple installation without additional drivers or external adapters.
-
Industrial-Grade Construction
Industrial-grade components are designed for reliable operation in demanding environments and support stable performance for extended operating periods.
-
Unidirectional Design
Optimized signal direction provides stable transmission. Connect the USB-C source end to the compatible source device and the HDMI end to the display.
Professional Applications
The USB-C to HDMI 2.1 Active Optical Cable is designed for professional systems requiring high bandwidth, long-distance connectivity, and stable visual performance.
Professional AV Systems
Connect USB-C source devices to HDMI displays across conference rooms, meeting spaces, training facilities, and commercial AV installations.
Broadcast & Media Production
Suitable for high-resolution video workflows, monitoring systems, production environments, and professional display infrastructure.
Conference Rooms
Provides a clean long-distance connection between USB-C laptops or computers and HDMI displays, projectors, and large-format presentation systems.
Commercial Displays & Digital Signage
Suitable for installations where source devices and displays are separated by extended cable distances.
Industrial Display Systems
The optical transmission architecture provides strong EMI/RFI immunity for demanding industrial environments.
High-Performance Computing & Visualization
Supports high-resolution display connectivity for compatible workstations, laptops, docking systems, and professional visualization environments.
Technical Specifications
| Specification |
Details |
| Source Interface |
USB-C |
| Display Interface |
HDMI |
| Cable Type |
Active Optical Cable (AOC) |
| Maximum Bandwidth |
48Gbps |
| Maximum Resolution |
Up to 8K@60Hz* |
| High Refresh Rate |
Up to 4K@120Hz* |
| Maximum Distance |
Up to 30m |
| Construction |
Hybrid Fiber + Copper |
| HDR |
Supported |
| DSC |
Supported |
| Dynamic HDR |
Supported |
| HDCP |
HDCP 2.3 |
| Power |
Bus-Powered |
| Driver |
Driver-Free |
| Hot Plug |
Supported |
| Auto Detection |
Supported |
| Direction |
Unidirectional |
| EMI/RFI |
Strong Interference Immunity |
| Primary Applications |
Professional AV / Broadcast / Industrial / Conference |
*Actual resolution, refresh rate, HDR features, and other display capabilities depend on the source device, USB-C port functionality, HDMI display, GPU, content, and overall system configuration.
Designed for Long-Distance USB-C to HDMI Connectivity
For AV system integrators, broadcast professionals, commercial installers, IT departments, conference-room solution providers, and industrial equipment manufacturers, the USB-C to HDMI 2.1 Active Optical Cable provides a practical solution for long-distance high-bandwidth display connectivity.
With 48Gbps bandwidth, 30m transmission capability, 8K@60Hz support, 4K@120Hz support, hybrid fiber construction, low-loss optical transmission, and strong EMI/RFI immunity, the cable is designed for demanding professional display environments.
Its driver-free, bus-powered, hot-plug, and unidirectional design simplifies installation while maintaining stable high-speed visual connectivity between compatible USB-C source devices and HDMI displays.
Compatibility
This is a USB-C source to HDMI display cable and is designed for unidirectional signal transmission.
The USB-C source device must support video output / DisplayPort Alt Mode through its USB-C port. Compatible source devices may include USB-C laptops, PCs, workstations, docking systems, and other video-enabled devices.
Before purchasing, please confirm that your USB-C source supports video output and that the connected HDMI display supports the desired resolution and refresh rate.
USB-C ports designed for charging or data transfer only are not compatible with video transmission.
