USB4 Type-C Female to Female Vertical-Angle Adapter – 40Gbps, 240W PD, 8K@60Hz

USB4 Type-C Female to Female Vertical-Angle Adapter – 40Gbps, 240W PD, 8K@60Hz

常规价格 $40.00 USD
常规价格 促销价 $40.00 USD
促销 售罄
已含税费。
数量


Designed for high-performance USB-C cable extension and space-constrained installations, this USB4 Type-C female-to-female vertical-angle adapter supports up to 40Gbps data transfer, 240W Power Delivery, and high-resolution video output up to 8K@60Hz.

Featuring USB-C female connectors on both ends, the adapter connects two compatible USB-C cables while redirecting the cable path vertically. This makes it useful for installations where a conventional straight coupler requires additional clearance or creates excessive cable bending.

The compact aluminum alloy housing provides durable mechanical protection and helps dissipate heat. A built-in LED indicator provides a convenient visual reference when power is present.

Key Features

  • 40Gbps USB4 Data Transfer – Supports up to 40Gbps bandwidth for compatible USB4 storage, docking stations, peripherals, and professional systems.

  • 240W USB-C Power Delivery – Supports up to 240W PD with a 48V/5A power profile when paired with compatible USB PD 3.1 equipment.

  • 8K@60Hz Video Output – Designed for high-resolution video applications, including up to 8K@60Hz and 4K@120Hz, depending on the connected system.

  • Female-to-Female USB-C Interface – Connects two compatible USB-C male cables through a compact inline adapter.

  • Vertical-Angle Design – Redirects the connected cables vertically to improve routing and installation flexibility.

  • Cable Extension Function – Allows compatible USB-C cables to be joined while changing their routing direction.

  • Space-Saving Structure – Helps reduce cable protrusion and improve clearance around equipment.

  • Aluminum Alloy Housing – Provides a durable enclosure and helps dissipate heat.

  • Built-in LED Indicator – Provides a convenient visual indication when power is present.

Professional Applications

USB-C Cable Extension

Connect two compatible USB-C cables when additional cable length is required while maintaining a vertical routing path.

USB4 Docking Stations

Suitable for extending USB4 connections between laptops, docking stations, hubs, and high-speed peripherals.

Monitor & Display Setups

Helps route USB-C display cables vertically behind monitors where space is limited.

High-Speed External Storage

Designed for compatible USB4 SSDs and other high-performance storage applications requiring high bandwidth.

Professional Workstations

Suitable for engineering, design, development, content creation, and other USB-C workstation environments.

OEM & System Integration

Useful for equipment integration, testing systems, desktop installations, and other applications requiring female-to-female USB-C connectivity with directional cable routing.

Technical Specifications

Specification Details
Product Type USB4 Type-C Female-to-Female Vertical-Angle Adapter
Connector 1 USB-C Female
Connector 2 USB-C Female
USB Standard USB4
Data Transfer Rate Up to 40Gbps
Power Delivery Up to 240W
PD Profile Up to 48V/5A
Video Output Up to 8K@60Hz / 4K@120Hz
Connection Type Female-to-Female
Design Vertical-Angle
Indicator Built-in LED
Housing Aluminum Alloy
Application Cable Extension, Dock, SSD, Display, Laptop, Workstation

Vertical-Angle Female-to-Female Connection

A standard USB-C female-to-female coupler creates a straight connection between two cables. In compact installations, however, a straight connection can force the cables to extend into surrounding equipment or bend sharply near the connector.

This adapter combines female-to-female USB-C connectivity with a vertical-angle structure, allowing two compatible USB-C cables to be joined while redirecting the connection path.

The design is useful for:

  • Extending existing USB-C cables

  • Changing the cable routing direction

  • Improving clearance around USB-C ports

  • Reducing unnecessary cable bending

  • Organizing cables behind monitors and docking stations

  • Creating cleaner connections in confined spaces

High-Bandwidth USB4 Connectivity

The adapter is designed for USB4 systems requiring high data bandwidth, high-power charging, and video connectivity in a compact form factor.

With support for up to 40Gbps data transfer, up to 240W Power Delivery, and high-resolution video applications, it provides a flexible connection solution for modern USB-C equipment.

Important Compatibility Note

Actual performance depends on the connected devices, cables, USB-C ports, and supported protocols.

  • 40Gbps requires compatible USB4 host, device, and cable hardware.

  • 240W charging requires compatible USB PD 3.1 source/device equipment and a suitable 240W-rated cable.

  • 8K@60Hz / 4K@120Hz requires compatible video-capable USB-C ports, display devices, cables, and supported video protocols.

  • Not every USB-C port or cable supports USB4, 40Gbps data, high-power PD, or video output.

  • The adapter does not increase the capabilities of the connected cables or devices.
